(Rosenfelt Inline Repeater RF 20-6B-L-T)
€2,199.00
In stock
SKU
RF 20-6B-L-T
- Call us for a customized offer!
- Suitable for all European networks (GSM VoLTE calls)
- Powerful all-in-one mobile booster for houses and buildings
- Easy to install. Ready for use
- Free of interference. CE! approved
- Low energy consumption
- Indoor coverage up to max. 20.000 sqm
- Art.nr. RF 20-6B-L-T
- Price excl. VAT
This 6-band Inline repeater, very powerfull, has been specially designed for installation in large venues such as: office buildings, hotels, exhibition halls, sports venues, conference halls, underground parks, warehouses, hospitals... This device completes any of our GSM and 4G repeaters and allows deployment of an extra line of 1 to 16 indoor antennas (depending on cabling configuration) allowing a total coverage worth 2000 sqm, per inline repeater.
Extremely flexible solution to deploy, several inline repeaters can be connected after a single GSM 4G repeater in order to create a very large system composed of multiple indoor antennas.
Please contact us for details and assistance on this 6-band 700+800+900+1800+2100+2600 MHz inline repeater Rosenfelt RF 20-6B-L-T. We are happy to assist further.
| Specifications | Suitable for 2G/3G/4G/5G on frequencies 700 - 800 - 900 - 1800 - 2100 - 2600 MHz |
|---|---|
| Coverage area | up to 20.000 sqm. |
| Gain Up | Uplink : 703 - 748MHz / 832 - 862MHz / 880 - 915MHz / 1710 - 1785MHz / 1920- 1980MHz / 2500 - 2570MHz |
| Gain Down | Downlink : 758 - 803 MHz / 791 - 821 MHz / 925 - 960 MHz / 1805 - 1880MHz / 2110 - 2170MHz / 2620MHz - 2690 MHz |
| Output power | 20dBm |
| Main Power | AC 100 ~ 240 V, 50/60 Hz, DC Adapter 12V 5A |
| Dimensions | 210 x 150 x 45 mm |
| Wavelength MHz | 700 MHz / 800 MHz / 900 MHz / 1800 MHz / 2100 MHz / 2600 MHz |
